Single-axis multi-station robot is also known as single-axis drive, single-axis robot, etc. Single-axis robots can realize multi-axis combinations through different combination styles, realize Cartesian coordinate robots, XZ multi-axis robots, and other applications. The single-axis manipulator is generally driven by a ball screw or a synchronous toothed belt and uses a precision linear guide as a guiding mechanism to realize functions such as handling, positioning, transfer, pick and place, and detection in a single direction.
The single-arm servo manipulator is a fully automatic conveyor designed for continuous automatic stamping operations of a punch multi-station punch. It is driven by a high-performance servo motor and passes through a precise transmission mechanism and material pick-and-place components such as vacuum suction cups, electromagnets, or clamping jaws. etc., the precise positioning and transfer between the stamping working die in the punching machine and the die can be stably and efficiently operated throughout the day, improving the punching rate of the punching machine and increasing the production capacity.
1. X, Z-axis handling mode, with the press to do single-action line movement
2. Flexible use, clamps, suction cups, electromagnets, and other clamping products
3. High stability and low input cost
4. It has unique advantages for special shape products
5. Small footprint and zero investment in the on-site foundation
6. The model is simple and can be used together with the feeder
1. The main rod is equipped with multiple sets of clamping jaws, which is suitable for the transfer of products using multiple sets of single-process molds under the action of the same press during the gradual molding process;
2. Running the main pole structure, the fixture is fixed on the main pole to lift and traverse as a whole. The equipment adopts a high-precision AC servo and PLC control system. The lifting part is connected by two reducers, the power is input at two points, and the movement is smooth.
3. The operation of the single-machine multi-station conveying manipulator is seven in one cycle: 1/2 stroke to the left → down → up → 1 stroke to the right → down → up → 1/2 stroke to the left ( produced from left to right). The product is transferred to the next station through such an action cycle. When the press is at the top dead center position, the manipulator starts to move; the gripper of the manipulator stops in the middle of the press (or in the middle of the two sets of molds). When the press is in a safe position between the central station and the press, the press goes down.
